AC19.5-M27x0.5

Adapter system mount Ø 19.5 mm to internal thread M27 x 0.5 mm

AC19.5-M27x0.5
AC19.5-M27x0.5
AC19.5-M27x0.5
AC19.5-M27x0.5

Features

The adapter AC19.5-M27x0.5 is an adapter from system mount Ø 19.5 mm to an internal thread M27x 0.5 mm. With this adapter you can attach the series 25 attachment optics to the fiber collimators series 60FC-L and 60FC-T with an outer diameter Ø 25 mm
  • System mount Ø 19.5 mm
  • Internal thread M27x 0.5 mm
  • Clear aperture Ø 12 mm
  • Black anodized aluminum

Technical data

AC19.5-M27x0.5

Order Code
AC19.5-M27x0.5
Adapter
Internal thread
System mount

M27 x 0.5 mm
Ø 19.5 mm


Steel ring
Clear aperture
Ø 15 mm
Material
Black anodized aluminum / steel
Weight
6 g
